Water Quality Unit
The ADS Water Quality unit traps hydrocarbons and removes total suspended solids to improve stormwater quality. The linear orientation makes the Water Quality Unit a great solution for applications that require shallow burial.
Water Quality Unit
WQU Install
WQU Install
WQU Install
Documents
- Storm Water Quality Unit Specification (PDF - 167 KB)
- TN 1.04 Testing of Storm Water Quality Units (PDF - 721 KB)
- TN 1.03 Storm Water Quality units (PDF - 158 KB)
- Water Quality Unit Installation Guide (PDF - 452 KB)
- Water Quality Units (PDF - 6 MB)
- Water Quality Unit Inspection and Maintenance Guide (PDF - 251 KB)
Overview
Two weir plates act as trapping devices as the stormwater flows through surface drainage structures and into the water quality unit. This structure also incorporates the use of a bypass system, which prevents re–suspension of captured solids by diverting water flows greater than 'first flush'.
Water Quality Units are durable, lightweight structures specifically designed for fast installation and easy maintenance. Made from high–density polyethylene N–12® drainage pipe, these units are resistant to abrasives and chemicals typically found in storm water and surrounding soils. And when site conditions require higher levels of treatment, the ADS Water Quality Unit becomes an integral part of a multi–tiered approach known as the treatment train.
Water Quality Units come in 16 standard models offering 36"-60" (900-1500 mm) diameters and 20' (6m) or 40' (12m) configurations, with longer lengths available upon request.
Features and Benefits
- Light weight
- Horizontal design for minimal depth excavation
- 80% TSS removal
- 80% oil and grease removal
- Short order lead time
Product Specifications
| ADS HDPE Water Quality Unit (WQU) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product Number | 3620WQA | 3640WQA | 3620WQB | 3640WQB | T4220WQA | 4240WQA | 4220WQB | 4240WQB | 4820WQB | 4840WQB | 6020WQA | 6040WQA | 6020WQB | 6040WQB |
| Diameter in. (mm) | 36 (900) | 36 (900) | 36 (900) | 36 (900) | 42 (1050) | 42 (1050) | 42 (1050) | 42 (1050) | 48 (1200) | 48 (1200) | 60 (1500) | 60 (1500) | 60 (1500) | 60 (1500) |
| Length ft. (m) | 20 (6) | 40 (12) | 20 (6) | 40 (12) | 20 (6) | 40 (12) | 20 (6) | 40 (12) | 20 (6) | 40 (12) | 20 (6) | 40 (12) | 20 (6) | 40 (12) |
| Inlet Size in. (mm) 10 (250) | 10 (250) | 10 (250) | 10 (250) | 10 (250) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 15 (375) | 15 (375) | 15 (375) | 15 (375) |
| Outlet Size in. (mm) | 10 (250) | 10 (250) | 10 (250) | 10 (250) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 12 (300) | 15 (375) | 15 (375) | 15 (375) | 15 (375) |
| Treated Flow Rate 1.5 (42) cfs (L/S) | 1.5 (42) | 2.38 (67) | 0.7 (20) | 1.6 (45) | 1.75 (49) | 3.66 (104) | 0.86 (24) | 1.83 (52) | 1.13 (32) | 2.39 (68) | 2.95 (84) | 6.23 (176) | 1.47 (42) | 3.12 (88) |
| Sed. Vol. ft.3 (m3) | 65 (1.8) | 137 (3.9) | 65 (1.8) | 137 (3.9) | 83 (2.3) | 175 (5.) | 83 (2.3) | 175 (5.) | 116 (3.3) | 245 (6.9) | 183 (5.2) | 385 (10.9) | 183 (5.2) | 385 (10.9) |
| Oil Vol. ft.3 (m3) | 30 (0.8) | 63 (1.8) | 30 (0.8) | 63 (1.8) | 38 (1.1) | 81 (2.3) | 38 (1.1) | 81 (2.3) | 55 (1.6) | 115 (3.3) | 87 (2.5) | 184 (5.2) | 87 (2.5) | 184 (5.2) |
| Sieve Size | 140 | 140 | 200 | 200 | 140 | 140 | 200 | 200 | 200 | 200 | 140 | 140 | 200 | 200 |
