Geosynthetic Non-Woven
Our non-woven geotextiles serve the purpose of soil filtration, roadway stabilization and other civil engineering projects. They are comprised of both needle punched and spunbonded, both of which are ideal for a variety of civil engineering applications.
Product Variations & Specifications
Product Specs
Product Details
Product Details
Documentation
Documentation
Product Specifications
| Non-Woven Geotextiles Specifications | |||
|---|---|---|---|
| Application | Specification | Category | Non-Woven |
| Subsurface Drainage | AASHTO M288 | Class 2 Class 3 | 601 451 |
| Roadway Separation | AASHTO M288 | Class 2 Class 3 | 601 451 |
| Roadway Stabilization | AASHTO M288 | Class 1 Class 2 | 801 601 |
| Erosion Control | AASHTO M288 | Class 1 Class 3 | 801 451 |
| Railroad Stabilization | AREMA/Ch. 1, Part 10 | Regular, Heavy, Extra Heavy | 1201 1601 170 |
| Leachate Collection/Detection | EPA/GRI Report No. 15 | N/A | 651 861 |
Product Details
Overview
Our geosynthetic non-woven fabric is made from a continuous polypropylene filament spun uniformly over a flat surface to make a flat, mat-like fiber. The crossed filaments are then thermally bonded together, rather than woven, into a tear-resistant material creating a filtration medium that offers excellent uniformity, puncture resistance and filtration efficiencies.
Features and Benefits
- Subsurface Drainage
- Roadway Separation
- Railroad Stabilization
- Hard Armor Underlayment
- Landfill Leachate Collection
- Underground Detention/Retention System
- Excellent tear resistance
- Excellent puncture resistance
- Increases performance life of roadways
- Offers filtration efficiencies
Documentation
0311T Non-Woven Geosynthetic Specification
0351T Non-Woven Geosynthetic Specification
0351T Nonwoven Geosynthetic Specification
0351TO Nonwoven Geosynthetic Specification
0401T Non-Woven Geosynthetic Specification
0451T Non-Woven Geosynthetic Specification
0501T Nonwoven Geosynthetic Specification
0601T Non-Woven Geosynthetic Specification
0601TO Nonwoven Geosynthetic Specification
0651 Non-Woven Geosynthetic Specification
0701T Nonwoven Geosynthetic Specification
0801T Non-Woven Geosynthetic Specification
0801TO Nonwoven Geosynthetic Specification
0861 Nonwoven Geosynthetic Specification
1001T Non-Woven Geosynthetic Specification
1071 Nonwoven Geosynthetic Specification
1201T Nonwoven Geosynthetic Specification
1291 Nonwoven Geosynthetic Specification
1601T Nonwoven Geosynthetic Specification
1601T Road Separator Fabric (black) Geosynthetic Specification
1601T Road Separator Fabric (white) Geosynthetic Specification
1701 Nonwoven Geosynthetic Specification
1701T Nonwoven Geosynthetic Specification
26-27 Septic Fabric Geosynthetic Specification
28-29 Septic Fabric Geosynthetic Specification
3151T Nonwoven Geosynthetic Specification
3201T Nonwoven Geosynthetic Specification
3301T Nonwoven Geosynthetic Specification
3401T Nonwoven Geosynthetic Specification
3601T Nonwoven Geosynthetic Specification
4597 Nonwoven Geosynthetic Specification
4598 Nonwoven Geosynthetic Specification
4599 Nonwoven Geosynthetic Specification
