Geosynthetic Erosion Control
We provide a comprehensive portfolio of cost-effective erosion control products to protect against soil loss. Our erosion control products control runoff within open channels, drainage ditches, swales and exposed slopes. As a global solutions network with a broad network of manufacturing plants and distribution centers, we offer unmatched distribution and logistics capabilities for all your project needs.
Documentation
Overview
We provide a line of erosion control products that can protect against soil loss in a wide variety of applications. Our products protect newly seeded soils from raindrop impact, minimize soil loss and promote infiltration to accelerate the development of seeds. On slopes, our products are more effective and economical than common alternatives like hydraulic mulch, blown straw or concrete slopes, saving you time and money. These erosion control products also help capture sediment and other contaminants from stormwater.
Products Available for Erosion Control
Silt fence fabrics have been recognized by the EPA as a Best Management Practice and offer a unique combination of UV resistance, strength and hydraulic properties. With sizes and stake spacing designed to meet each state’s DOT specification, our silt fences provide straightforward installation and simple design.
Our Turf Reinforcement Mats (TRMs) are the ideal product for long-term erosion protection on slopes and in channels. Made of flexible, three-dimensional polypropylene, they have a superior design life that can handle the stress of high velocities on difficult slopes.
GeoCell and GeoCell GS panels have a lightweight three-dimensional confinement system using the strength and permeability of geotextile fabric. The panels can be used on different terrains as the design is adaptable and configurable and can be ordered in multiple sizes.
Degradable erosion control blankets act as dimensionally stable, reinforced mulches to hold seeds and soil in place until vegetation is established in short and medium-term projects. They are available in many varieties, from all-natural to synthetic reinforced.
Wattles are a cost-effective erosion control solution designed to curb the effects of medium to high-velocity storm and water runoff. They are composed of weed-free straw and designed to be used in channels and for perimeter sediment control.
Product Specifications
ADS GEOSYNTHETICS 3301W WOVEN GEOTEXTILE | |||
---|---|---|---|
Filter Fabric Properties | Test Method | Typical Roll Value (English) | Typical Roll Value (Metric) |
Grab Tensile | ASTM D-4632 | 80 lb | 0.356 KN |
Elongation | ASTM D-4632 | 15% | 15% |
Mullen Burst | ASTM D-3786 | 180 psi | 1241.06 kPa |
Puncture | ASTM D-4833 | 35 lb | 0.156 KN |
Trap Tear | ASTM D-4533 | 35 lb | 0.156 KN |
AOS | ASTM D-4751 | 30 US Sieve | 0.600 mm |
Permittivity | ASTM D-4491 | 0.05 sec-1 | 0.05 sec-1 |
Turf Reinforcement Mats | |||||||
---|---|---|---|---|---|---|---|
Property | Test Method | Units | PP58GTR | PP510GTR | PP512GTR | PP5HD | PP5-XTREME |
Thickness | ASTM D6525 | in; mm | 0.34; 0 | 0.36; 0 | 0.38; 0 | 0.30; 0 | 0.30; 0 |
Tensile Strength | ASTM D6818 | lb/ft; kN/m | 20.8 x 17.7; 3.6 x 3.1 | 20.8 x 17.7; 3.6 x 3.1 | 20.8 x 17.7; 3.6 x 3.1 | 2,500 x 2,250; 36 x 33 | 4,000 x 3,000; 59 x 44 |
Elongation | ASTM D6818 | % | 25 x 24 | 25 x 25 | 25 x 25 | 25 x 20 | 25 x 22 |
Mass Per Unit Area | ASTM D6566 | oz/yd; g/m2 | 8.0; 271 | 10.0; 399 | 12.0; 407 | 9.2; 312 | 9.2; 312 |
Light Penetration | ASTM D6567 | % | 35% open | 25% open | 20% open | 25-30% open | 25-30% open |
Water Absorption | ASTM D1117 | % | N/A | N/A | N/A | N/A | N/A |
Resiliency | ASTM D6524 | % | 89% | 87% | 88% | 95% | 95% |
Porosity | Computed | % | 97% | 96% | 96% | 96% | 96% |
UV Stablilization | ASTM D4355 | % | 100% (500 hr); 90% (1,000 hr) | 100% (500 hr); 90% (1,000 hr) | 100% (500 hr); 90% (1,000 hr) | 100% (500 hr); 90% (1,000 hr) | 100% (500 hr); 90% (1,000 hr) |
ADS GEOSYNTHETICS 3302W AASHTO GRADE WOVEN GEOTEXTILE | |||
---|---|---|---|
Filter Fabric Properties | Test Method | Typical Roll Value (English) | Typical Roll Value (Metric) |
Grab Tensile | ASTM D-4632 | 125 x 124 lb | 0.556 x 0.551.6 N |
Grab Elongation | ASTM D-4632 | 15% x 15% | 15% x 15% |
CBR Puncture Strength | ASTM-D- 6241 | 325 lb | 1445.7 N |
Trapezoidal Tear | ASTM-D- 4533 | 65 x 65 lb | 0.289.1 x 0.289.1 N |
UV Resistance @ 500 hours | ASTM-D- 4355 | 70% | 70% |
Apparent Opening Size (Max. Average Roll Values) | ASTM D-4751 | 30 US Sieve | 0.60 mm |
Permittivity | ASTM D-4491 | 0.1 sec-1 | 0.1 sec-1 |
Water Flow Rate | ASTM D-4491 | 8 gpm/ft2 | 326 lpm/m2 |
Geo Cell Specifications | ||||
---|---|---|---|---|
Geocells - Typar | 350/100 | 350/150 | 250/100 | 220/200 |
Cell Depth | 4” (10.16 cm) | 6” (15.24 cm) | N/A | N/A |
Panel Diameter | 16.4’ x23’ (5 m x 7.01 m) | 16.4’ x23’ (5 m x 7.01 m) | 16.4’ x23’ (5 m x 7.01 m) | 10’ x 20’ (3.05 m x 6.10 m) |
Cell Diameter | 14” (10.16 cm) | 14” (10.16 cm) | 10” (25.40 cm) | 8” (20.23 cm) |
Square Feet/Square Meter | 377 (114.91) | 377 (114.91) | 377 (114.91) | 200 (60.96) |
Erosion Control Blankets (ECB) Specifications | ||||||||
---|---|---|---|---|---|---|---|---|
Property | Test Method | Units | OOS1TT | OOS2TT | OCS2TT | OOC2TT | OOS2AN | OCS2AN |
Thickness | ASTM D6525 | in; mm | 0.28; 7 | 0.28; 7 | 0.34; 7 | 0.26; 7 | 0.28; 0 | 0.34; 0 |
Tensile Strength | ASTM D6818 | lb/ft; kN/m | 4.8; 0.8 | 10.0; 1.8 | 13.0; 2.3 | 18.4; 3.2 | 16.0;2.8 | 16.0;2.8 |
Elongation | ASTM D6818 | % | 15 md; 20 td | 20 md; 26 td | 31 md; 29 td | 25 md; 25 td | N/A | N/A |
Mass Per Unit Area | ASTM D6566 | oz/yd; g/m | 8.0; 271 | 8.0; 271 | 8.9; 302 | 9.5; 322 | 8.0; 271 | 8.9; 302 |
Functional Longevity | ASTM | Months | 12 | 12 | 24 | 36 | 12 | 24 |
ADS Straw Wattles Specifications | |||
---|---|---|---|
Diameter | 9” (22.86 cm) | 12” (30.48 cm) | 20” (50.8 cm) |
Lengths Available | 10’ (3.048 m), 20’ (6.096 m), 25’ (7.62 m) | 10’ (3.048 m), 20’ (6.096 m), 25’ (7.62 m) | 20’ (6.096 m), 25’ (7.62 m) |
