12" - 30" Fabricated Water Tight Gasket-Gasket 90 Degree Manifold Bends (HDPE Dual Wall Fabricated Manifolds Fittings)

This document is the 12" - 30" Fabricated Water Tight Gasket-Gasket 90 Degree Manifold Bends (HDPE Dual Wall Fabricated Manifolds Fittings). A bend diagram with table provided.

The dual wall fabricated “Water Tight” “Gasket-Gasket” Manifold Bend 36" - 60" diameter is shown in a diagram that shows A dimensions.

A table with the information for part number, pipe size and A sizes is provided.

All fittings dimensions are for reference only.
