The Nyloplast Product Guide Brochure outlines the matrix of dimensions, applications, accessories, part numbers and cost comparison for all products.

The minimum angle chart is a quick reference for adapters 4”-04” to 30”-30” and basins 8”-30”. It is not used for snout or weir structures.

Inline drains has a chart with part #, description and available outlets. A detail explains when inline drains are used.

On the following pages, there is more detailed information on 8” & 10”, 12” & 15”, 18”, 24” and 30” inline drains with dimensions, illustrations, charts and options.

Drain basins has a chart with part #, description and available outlets. A detail explains when inline drains are used.

On the following pages, there is more detailed information on 8” & 10”, 12” & 15”, 18”, 24” and 30” drain basins with dimensions, illustrations, charts and options.

Curb inlet structures has a chart with part #, description and available outlets. A detail explains when inline drains are used.

On the following pages, there is more detailed information on curb inlets with 2’x2’ grate, 2’x3’ grate with dimensions, illustrations, charts and options.

Road & Highway structures has a chart with part #, description and available outlets. A steel bar grate and frame guide is included.

Road & Highway with 2’x2’ grate has a detail of the structure with dimension chart and grate options. Road & Highway with 2’x3’ grate has a detail of the structure with dimension chart and grate options.

Riser section has a detail of the structure with dimension chart.

Drop in grates has a detail of the structure and overview chart with dimensions. A grate ordering worksheet features formulas, styles, grate types and assembly options.

Grate options for inline drains & basins shows an illustration of each grate type, curb inlets, Road & Highway grates and grate riser extensions. Grate only part number list follows.

Accessories highlight Inserta-TEE, EnviroHood, Flexstorm Catch-It and Flexstorm Pure.

Weir structure information about how it works, benefits, overview chart and how to order includes alternate pipe connections, pour rings and perforations.

Drain basin configurator shows how to do it yourself, followed by instructions on how to build a part number.

Lastly, a drainage structure cost comparison, manufacturing & service locations, terms & conditions and ADS company information and contacts ends the brochure.
