30"-60" Tee - IB Bell/IB Spigot/IB Bell (HP Storm Tees Fittings Manual)
Filename:
30"-60" Tee - IB Bell/IB Spigot/IB Bell (HP Storm Tees Fittings Manual).pdf
This document is the HP Storm Dual Wall Fabricated Tees. Table with pipe size and diagram with descriptions included.
The HP Storm Dual Wall Fabricated Tees 30”-60” diameter (IB Bell/IB Spigot/IB Bell) is shown with a chart that lists the values for Part number, pipe size, A/B/C/D and Joint. Diagram with WT includes 4 gaskets.
