904A Arc 36 HC Side Port Coupler Detail

Filename:
904A Arc 36 HC Side Port Coupler Detail.dwg

Download Document (dwg)
904A Arc 36 HC Side Port Coupler Detail

This document is the 904A Arc 36 HC Side Port Coupler Detail. Details show the coupler feed with descriptions and dimensions.

The details show the post end, dome end, 14” installed length, 10.5” invert height and various dimensions of the coupler.

904A Arc 36 HC Side Port Coupler Detail
